CPLD, FPGA, ASIC: Selection Logic and Typical Applications
In digital circuit design, CPLDs, FPGAs and ASICs represent three distinct implementation paths.
A CPLD (complex programmable logic device) targets relatively small-scale logic circuits. It uses a fixed internal interconnect architecture, with macrocells typically numbering in the hundreds. CPLDs are non-volatile and operate as soon as power is applied. An FPGA (field-programmable gate array) features configurable logic cells and abundant routing resources. Its logic capacity can reach millions of cells, and it supports prototyping and short-term product development, but it usually requires external configuration memory. An ASIC (application-specific integrated circuit) is customized at the transistor level for a specific function. It can simultaneously achieve high performance, low power and small size, but it cannot be modified after design completion.
Cost and Performance Trade-offs
The key to selection lies in understanding the different cost curves of the three options. An ASIC carries mask and NRE (non-recurring engineering) costs. Initial investment is extremely high, but per-unit cost drops significantly once mass production begins, giving it a clear advantage when product volumes reach tens of thousands of units or more. FPGAs and CPLDs require low initial investment and allow design and trial production at the sample level, but their per-unit cost is higher than that of a mass-produced ASIC.
In terms of performance, ASICs are optimized at the transistor level and offer the highest speed and energy efficiency. FPGAs are affected by routing delays between logic cells and logic overhead, resulting in higher power consumption and larger area. CPLDs have limited logic capacity and relatively lower clock frequencies, but they offer good power control and predictable timing delays—their centralized interconnect matrix provides uniform delay, making them ideal for timing-sensitive glue logic.
Typical Application Scenarios
CPLDs are commonly used for glue logic around microcontrollers and sensors, I/O expansion, address decoding, power sequencing, and protocol interface management such as SPI, I²C and UART. FPGAs are widely deployed in communications infrastructure, image processing, AI edge inference, high-speed interface bridging, and ASIC prototyping. ASICs are concentrated in high-volume, long-lifecycle scenarios such as consumer electronics main controllers, automotive electronics, network switching chips, and customized AI accelerators.
Popular Classic Models for Reference
Type | Model | Mfr | Key Specifications |
CPLD | AMD/Xilinx | 72 macrocells, 1.6K gates, 3.3V, TQFP-100 | |
CPLD | Lattice | 128 macrocells, 3.3V, TQFP-100 | |
FPGA | AMD/Xilinx | Kintex-7, 300 I/O, FCBGA-901 | |
FPGA | Intel/Altera | Cyclone IV E, 115K logic elements | |
FPGA | Lattice | MachXO2 series, low power, TQFP-100 |
